HIKVISION CAT6 305 METER CABLE

4999.00 5120.00 Save 121 (2.36%)

Available: In Stock
Highlights
  • BRAND HIKVISION
  • TRANSMISSION DISTANCE UP TO 85M
  • CPR CERTIFICATE WHITE
  • UTP CAT 6, SOLID-BARE COPPER, 305 METERS 0.585MM, CCA
  • FOR ANY OTHER QUERY GO TO HELP OPTION ON OUR WEBSITE
Offers
  • 5% DISCOUNT ON MINIMUM PURCHASE OF 2000 UP TO RS 250 ON UPI PAYMENT
  • BANK OFFER: 5% INSTANT DISCOUNT ON ALL BANK DEBIT CREDIT CARD
Wishlist
  • Product Code: #245
  • Category: CABLES

·         Category

CAT. 6 CCA U/UTP 4x2x23awg/1 PVC

·         Conductor

·         Material

CCACopper Content 27%

·         Nom.O.D.(Mm)

0.585±0.01

·         Insulation

·         Material

Solid HDPE

·         Diameter

1.05±0.05mm

·         Sheath

·         Thickness

0.50±0.05 Mm

·         External O.D.

6.0±0.30 Mm

·         Surface

Clean, Frap, Satiation

·         Material

PVC(Complies Rohs)

·         Color

White RAL9003

·         Surface Printing

·         Letter Height

2.5±0.2mm

·         Color

Black

·         Print Error & Space

≤±0.5% 1m

·         Other Properties

·         Core Color

1 Blue & White/ Blue
2 Orange & White/ Orange
3 Green & White/ Green
4 Brown & White/ Brown

·         Packing

Carton

·         Carton Dimension

42x42x24cm

·         Packing Length

(305±1.5)M

·         Electrical Characteristics (20)

1.0-100.0mhz Impedance(Ω) 100±15
100 - 250mhz Impedance(Ω) 100±25
1.0-100.0mhz Delay Shew (Ns/100m) ≤45
DC Resistanceω/100m) Max 12
DC Conductor Resistance Unbalance(%) Max 2

·         Ambient Temperature

-20 - 70





·         Weight

0.0544 kg

·         Dimensions

41 × 41 × 24 cm

·         Brand

Hikvision

·         Conductor

Material – Nom.O.D.(mm)
CCA
Copper content27%- 0.585 Up : +0.01 Down : -0.01

·         Insulation

Material – Solid HDPE Diameter – 1.05±0.05mm

·         Sheath

Thickness 0.50±0.05 mm External O.D. 6.0±0.30 mm
Surface Clean, Frap, Satiation
Material FR-PVC(complies RoHS) Color White RAL9003

·         Core Color

1 Blue & White/ Blue 2 Orange & White/ Orange
3 Green & White/ Green 4 Brown & White/ Brown

·         Packing length

(305±1.5)m

·         Sheath Physical Properties

Before Aging Tensile Strength (Mpa) ≥13.5
Elongation(%) ≥150
Aging Period(
×hrs) 100×24h×7d
After Aging
Tensile Strength(Mpa) ≥12.5, variance ratio:±25%
Elongation(%) ≥125, variance ratio:±20%

·         Electrical Characteristics (20)

1.0-100.0MHz Impedance(Ω) 100±15
100 – 250MHz Impedance(Ω) 100±25
1.0-100.0MHz Delay Shew (ns/100m) ≤45
DC ResistanceΩ/100m) max 12

DC Conductor Resistance Unbalance(%) max 2
